Kamis, 13 Maret 2025

Mesin Uji Marshall, UCS dan CBR 34-V1182

Model : 34-V1182, 34-V1184

Brand/Supplied From : Controls – Italy




Standards
* CBR: EN 13286-47, ASTM D1883
* Marshall: EN 12697-34, ASTM D1559, D5581, D6927
* Indirect Tensile: EN 12697-23, ASTM D4123, AASHTO T283 (padanan SNI 6753 : 2015)
* Unconfined compression: ASTM D2166, BS 1337
* Quick triaxial: AST D2850, BS 1337
* Indirect tensile on bituminous mixtures: EN 12697-12, EN 12697-23, ASTM D4123, CNR 34

Referensi Standard RSNI M-06-2004: Cara uji campuran beraspal panas untuk ukuran agregat maksimum dari 25,4 mm (1
inc) sampai dengan 38 mm (1,5 inci) dengan alat marshall

Description

A flexible standalone machine, the new Automatic Universal Tester with Touch Screen Digital Speed Control and Data Acquisition, or MULTILOADER, is the smart choice for road testing labs and generally for any test that requires displacement/speed control. In addition to CBR and Marshall tests, the 50kN capacity and fully variable speed of 0.05 to 51 mm/min enable many other applications, including quick undrained triaxial and unconfined/uniaxial soil tests, indirect tensile strength, IDEAL-CT, semi-circular bend, and Leutner shear tests.

Technical Specifications

  • Data download: Ethernet port, RS232 port or USB pendrive
  • Memory: 16GB internal memory
  • Number of channels: 7 (1 for actuator displacement, 2 for load and 4 for displacement)
  • Channel resolution: 24 bit
  • Sampling frequency: up to 100Hz
  • Test speed: from 0.05 to 51 mm/min
  • Type of control: displacement
  • Max ram travel: 100 mm
  • Max vertical span: 765 mm
  • Max horizontal span: 270 mm
  • Overall dimensions: 435 x 670 x 1265 mm (W x D x H)
  • Weight approx: 110 kg
Ordering Info:
34-V1182 MULTILOADER automatic compression testing machine with digital control and readout unit, motorized ram, two-column structure and adjustable crossbeam. 220-240V/50-60Hz/1Ph


Info/Price : Yudhistira, ST

Hp. 0811 188 6845; 0818 0816 0634 (WA)

Email : naysite2@gmail.com

Rabu, 12 Maret 2025

Direct and Residual Shear Testing Machine AUTOSHEAR

Brand/Supplied From : Controls – Italy

Standard : ASTM D3080 (Padanan SNI 2813 : 2008), AASHTO T236 (Setara dengan SNI 3420:2016), BS 1377:7, CEN-ISO/TS 17892-10, NF P94-071



ASTM 3080 : 1.1 This test method covers the determination of the consolidated drained shear strength of a soil material in direct shear

SNI 2813:2008 : Cara Uji Kuat Geser Langsung Tanah Terkonsolidasi dan Terdrainase

BS 1377-7:1990: The Standard for Methods of test for soils for civil engineering purposes - Shear strength tests (total stress)



Features :

·     User interface 6″ touch screen colour display for numerical and graphical plotting of the readings

·     Maximum horizontal force: 5 kN

·     Maximum vertical force: 5 kN, using the 10:1 cantilever device

·     Three analogue channels. one for load cell and two for displacement transducers

·     Effective channel resolution: 131,000 points

·     Infinitely variable speed from 0.00001 to 15.0000 mm/min

·     High stiffness load chain shear box – driving head – load cell

·     Compatible with shear boxes up to 100 mm diameter or square

·     USB pen drive for unlimited storage capacity and TXT format data output

·     Optional PC control via LAN port and dedicated software

·     Sturdy shear box techno-polymeric carriage untouchable by corrosion

·     Adjustable speed and travel (forward and reverse) for residual shear test

·     Number of cycles adjustable from 1 to 50

·     Specific and independent data recording for consolidation and failure stages



Description

The Autoshear is an automatic machine for direct/residual shear testing. It incorporates a high-resolution stepper motor fitted with a high precision load transfer mechanism.
Via the large 6" touch screen colour display the user can start, pause and stop the test, select the data-recording mode, view the readings and the diagrams during the test execution and carry out the transducers calibration (load cell and two displacement transducers).
The axial transmission of the horizontal force adopts a straight connection through shear box, shaft and load cell. This design avoids the load measurement inaccuracies occurring with the widely used "swan neck" basic design.
A high quality techno-polymeric material has been adopted for the carriage of the shear box, offering excellent resistance to corrosion, wear and tear and to the chemicals often mixed with the soil specimens.
Furthermore, this polymeric carriage is lightweight and easy to clean.
Vertical load is applied directly to the specimen via a loading yoke and a weights holding arm which amplifies 10 times the applied value.
Load cell and displacement transducers, weight and shear box assembly shall be ordered separately (see accessories and related products)
Load ring and dial gauge are also suitable for manual recording.



Standard complete configuration is composed by:

  • Autoshear
  • Shear box (see accessories and related products)
  • Vertical displacement transducer (see accessories and related products)
  • Horizontal displacement transducer (see accessories and related products)
  • Load cell (see accessories and related products)
  • Set of Weight (see accessories and related products)
  • Template for data processing (see accessories)



Technical Specifications

  • Maximum shear force: 5000 N
  • Maximum vertical load: 500 N or 5000 N using 10:1 cantilever loading device supplied with the machine
  • Maximum horizontal travel: 23 mm
  • Test speed: from 0.00001 to 15.00000 mm/min
  • Maximum number of  a shear cycles: 50
  • Sample type and size: up to 100 mm square or round
  • Overall dimensions: 1040 x 530 x 1200 mm (l x d x h)
  • Weight approx.: 60 kg
  • Multivoltage: Multifrequency power supply 230 V, 50 Hz or 110 V, 60 Hz



Ordering Info :

27-WF21A60 Autoshear, direct and residual shear testing machine with automatic built-in data acquisition
100-220 V, 50-60 Hz, 1 ph



Price/Info : Yudhistira, ST

Hp. 0811 188 6845; 0818 0816 0634(WA)

Email : naysite2@gmail.com



Automatic Computerized Oedometer ACE EmS - Mesin Uji "konsolidasi" dengan Elektromekanikal - tanpa slot pembebanan




Brand/Supplied From : Wykeham Farrance, ControlsGroup – Italy

Model : 26 - WF31E20



Standard : AS 1289.6.6.1, ASTM D2435(padanan SNI 2812 : 2011), ASTM D3877, ASTM D4546, BS 1377:5, EN 17892-5, NF P94-091



ASTM D2435 : 1.1 This test method covers procedures for determining the magnitude and rate of consolidation of soil when it is restrained laterally and drained axially while subjected to incrementally applied controlled-stress loading.

SNI 2812 : 2011 : Metode ini digunakan dalam pengujian beban titik pada benda uji batu berbentuk silinder, balok dan tak teratur. Tujuan untuk mendapatkan indek kekuatan batu dengan beban titik untuk menentukan klasifikasi batu secara cepat.

ASTM D3877 : 1.1 These test methods provide procedures for conducting expansion, shrinkage, and uplift pressure tests on compacted soil-lime mixtures and can be used to determine the lime content required to achieve desired control of volume changes caused by increases or decreases of moisture



Fitur Utama :

  • Mesin Uji konsolidasi tanah Oedometer otomatis yang menampilkan pemuatan tambahan, pembengkakan, CRS (laju regangan konstan), CHG (gradien hidraulik terkendali) dan pengujian tanpa batas.
  • Ramah lingkungan dan tenang - ACE EmS mendapatkan manfaat dari teknologi Elektromekanik Servoaktuasi (EmS) baru yang tidak memerlukan beban mati atau kompresor udara besar & berisik, sehingga secara drastis mengurangi tingkat kebisingan.
  • Modular dan dapat diperluas, secara bertahap menghubungkan hingga 60 unit melalui port LAN menggunakan perangkat lunak PC yang sama yang memungkinkan Anda membangun laboratorium tanpa gangguan - menghasilkan pengembalian investasi yang sangat baik.
  • Menggunakan dimensi mesin berukuran lebih kecil yang menampilkan benchtop lebih pendek dari 50 cm.
  • Berkinerja tinggi dengan kapasitas beban hingga 20 kN, setara dengan 10.000 kPa pada 50,47mm sel konsolidasi Oedometer.
  • Kontrol putaran-tertutup PID yang dioptimalkan memberikan pemuatan yang cepat, lancar dan akurat serta pemuatan beban yang tepat melalui beberapa langkah pengujian.
  • Opsional Antarmuka pengguna lokal dengan layar sentuh 6 inci warna resolusi tinggi memungkinkan kontrol penuh dari satu unit, tanpa PC, termasuk pelaksanaan tes penuh. USB pen drive disertakan untuk penyimpanan tak terbatas, output data format TXT.

General Descriptions :

The ACE EmS is a versatile and fully automatic Oedometer soil consolidation testing machine that comes loaded with the new environmentally friendly Electromechanical Servoactuation (EmS) technology. Silent, compact and highly performing, the ACE EmS testing system can be run with our ingenious software that can connect up to 60 units with just one PC, enabling you to expand your laboratory gradually and seamlessly.



Spesfikasi Teknis :

  • Maximum vertical force: 20 kN
  • Ram travel: 25 mm
  • Minimum testing speed: 0.00001 mm/min
  • Maximum testing speed: 50.00000 mm/min
  • Horizontal clearance: 175 mm
  • Vertical Clearance: 185 mm (265 mm with extension columns)
  • Dimension: 285 x 390 x 590 mm
  • Weights 40 kg (approx.)
  • Power: 220-110 V, 50-60 Hz, 1 ph
  • Power consumption: 600 W



Price/Info : Yudhistira, ST

Hp. 0811 188 6845; 0818 0816 0634(WA)

Email : naysite2@gmail.com





Selasa, 11 Maret 2025

Gyratory compactor GYROCOMP 78-PV2522

Brand : IPC/ControlsGroup – Italia

Kode Barang : 78-PV2522 (AASHTO T312 and ASTM D6925), 78-PV2522/E (EN 12697-31 Annex B)

Standard : EN 12697-10, EN 12697-31, AASHTO T312, SHRP M-002, ASTM D6925



ASTM D6925 : 1.1 This standard concerns the compaction of cylindrical specimens of hot mix asphalt (HMA) using the Superpave Gyratory Compactor (SGC).

AASHTO T312 : Preparing and Determining the Density of Hot-Mix Asphalt (HMA) Specimens by means of the Superpave Gyratory Compactor

EN 12697-10 : This document describes three test methods for characterizing the compactability of a bituminous mix, by the relation between its density or void content and the compaction energy applied to it, using an impact (Marshall) compactor, gyratory compactor, or a vibratory compactor



Features :

  • Touchscreen display, with possibility to modify, save and recall a large range of testing procedure for fast test performance
  • Vertical force by pneumatic actuator (compressed air required)
  • High productivity, designed for continuous and heavy use
  • High rigidity thus lightweight due to the propriety orbital system
  • Compact and lightweight, also ideal for mobile laboratories
  • Very reliable and accurate
  • Certified to EN and AASHTO
  • Approved as Superpave™ Gyratory Compactor in U.S.A.
  • Sliding transparent door
  • Full safety and ergonomic design
  • Integrated electromechanical extruder option
  • Large range of accessories available



Highlights:
Gyratory Compactors enable engineers to reproduce real-world compaction conditions during road paving operations, allowing them to ascertain the compaction qualities of an asphalt mixture.



Light and portable, GYROCOMP represents the ideal solution for Quality Control (QC) and can even be easily installed in mobile laboratories, representing the ideal solution for Quality Control (QC).



Specifications :



  • Compacted specimen size: 150 and 100 mm dia.
  • Sample height: 80 to 200 mm (150 mm), 50 to 125 mm (100 mm)
  • Consolidation pressure: 80 to 800 kPa (150 mm); 160 to 1400 kPa (100 mm)
  • Internal angle of gyration: Adjustable from 0.70 to 1.40°.
  • Preset to 1.16° internal angle (78-PV2522)
  • Preset to 0.82° internal angle (78-PV2522/E)
  • Speed of gyration: adjustable from 20 to 60 rpm
  • Number of gyrations: adjustable up to 999
  • Test programmable either by number of gyrations or specimen height
  • Communication with PC: Ethernet for PC connection, USB for data storage on USB stick
  • Power rating: 1700 W
  • Dimensions (including extruder bench, W x D x H): 502 x 753 x 1940 mm
  • Dimensions (W x D x H): 469 x 615 x 1130 mm
  • Weight approx.: 100 kg (without extruder) 150 kg (with extruder)



Ordering Info :

78-PV2522 GYROCOMP gyratory compactor, internal angle of gyration pre-set to 1.16° to AASHTO T312 and ASTM D6925.110-230V/50-60Hz/1ph

78-PV2522/E GYROCOMP gyratory compactor, internal angle of gyration pre-set to 0.82°to EN 12697-31 Annex B. 230-110V/50-60Hz/1ph



Accessories :

Cylinder moulds and distance plates

78-PV0250/2 Cylinder mould 150 mm dia., special alloy steel hardened to 53-55 HRC, internally grinded. Complete with top and bottom plates.

78-PV0250/5 Cylinder mould 100 mm dia., special alloy steel hardened to 53-55 HRC, internally grinded. Complete with top and bottom plates.

78-PV0250/10 Cylinder mould 150 mm dia., special alloy steel hardened to 53-55 HRC, internally grinded, with holes for cold mix compaction. Complete with top and bottom plates

78-PV0250/8 Cylinder mould 100 mm dia., special alloy steel hardened to 53-55 HRC, internally grinded, with holes for cold mix compaction. Complete with top and bottom plates

78-PV0250/3   Distance plate, 150 mm dia., 50 mm high, for preparing short samples

78-PV0250/6  Distance plate, 100 mm dia., 38 mm high, for preparing short samples

78-PV0250/4  Accessories to compact 100 mm dia. specimens including 100 mm height calibration device

Integrated work top with extruder

78-PV2520/15  Integrated work top with electromechanical specimen extruder. 230 V, 50-60 Hz, 1 ph

78-PV2520/15Z  Integrated work top with electromechanical specimen extruder. 110 V, 60 Hz, 1 ph



Kategori : Alat uji Aspal

Price/Info: Yudhistira, ST.

Hp. 0811 188 6845; 0818 0816 0634(WA)

Email : naysite2@gmail.com

Fully Electro-Mechanical Gyratory Compactor GALILEO

Merek/Suplied From : IPC/ControlsGroup – Italia

Kode Barang : 78-PV20G02,

Standard : EN 12697-10, EN 12697-31, AASHTO T312, ASTM D6925, AS 2891.2.2 (Setara dengan SNI 03-6838-2002)



ASTM D6925 : 1.1 This standard concerns the compaction of cylindrical specimens of hot mix asphalt (HMA) using the Superpave Gyratory Compactor (SGC).

AASHTO T312 : Preparing and Determining the Density of Hot-Mix Asphalt (HMA) Specimens by means of the Superpave Gyratory Compactor

SNI 03-6838-2002 : Tata cara penyiapan benda uji - Pemadatan contoh uji campuran beraspal dengan menggunakan alat pemadat giratori.

EN 12697-10 : This document describes three test methods for characterizing the compactability of a bituminous mix, by the relation between its density or void content and the compaction energy applied to it, using an impact (Marshall) compactor, gyratory compactor, or a vibratory compactor.



Main Features

  • High precision, robust load mechanism combined with an extremely rigid frame assures high accuracy and repeatability
  • Load cell fitted directly on the vertical actuator for accurate load measurement and feedback control
  • Quick and easy manual/mechanical adjustment of the gyratory angle shown on the display
  • User defined axial stress and speed of rotation
  • Sliding transparent door with safety interlock
  • Catch tray to collect expelled liquids using perforated moulds
  • Fresh concrete configuration available
  • Easy control using the integrated 7" colour touchscreen panel or connected PC
  • User friendly PC software for data analysis and tests set up. Remote communication is available to receive immediate diagnostics
  • Automatic data saving on USB or on Windows PC
  • Lightweight yet robust moulds strictly comply with international Standards
  • Safe and easy mould insertion and extraction with automatic lifting ensures low effort for the operator and higher productivity
  • Simultaneous extraction of last specimen for higher productivity
  • Easy specimen extraction with the integrated extruder
  • Mounted on swivel caster wheels for easy moving and positioning
  • Real-time direct shear and torque resistance measurement. Automatic calculation of the compaction energy (optional)



Operating principle

Standard specify the method for compaction of cylindrical specimens of bituminous mixtures using a gyratory compactor. Such compaction is achieved by combining a rotary shearing action with a vertical static force applied by a mechanical head.

The method can be used for:

  • Preparation of specimens of a given height at a predetermined density, for subsequent testing of their mechanical properties;
  • Derivation of a curve of density versus number of gyrations;
  • Void content for a given number of gyrations.



Standards apply to bituminous mixtures (made either in laboratory or from on-site sampling), with aggregates not larger than 37.5 mm. During operation the bituminous mixture is contained in a cylindrical mould (100 or 150 mm diameter). Compaction is achieved by the simultaneous application of a low-static compression and a shearing action, which results in the motion of the centre-line of the test piece, which generates a conical surface of revolution while the ends of the test piece remain approximately perpendicular to the axis of the conical surface.



Technical Specifications

Model

Galileo 78-PV20G0X

Consolidation pressure

10 – 1000 kPa for 150 mm diam.
25 – 2200 kPa for 100 mm diam.

Gyratory motion and
Vertical load

Electromechanical

Angle adjustment

Manual

Gyratory angle range

0 -3° ±0.01

Gyratory angle measurement

Angle measured and displayed during test

Zero angle at the end of the test

No

Speed of gyration

5 – 60 rpm (120 on request)

Number of gyrations

0 -9999

Integrated Shear measurement

Yes (optional)

Moulds dimensions

100 and 150 mm diam., 250 mm height.

User interface

7” 16:9 Touch screen color display
(PC for data analysis)

Connection

LAN - Ethernet

PC Software

Available as option

Extruder

Available as option (electromechanical)

Balance

Available as option with an accuracy of 1 g

Minimum specimen height

50 mm

Maximum specimen height

Up to 200 mm depending on mix type

Height accuracy

Better than 0,1 mm

Suitable for water pouring test

Yes

Suitable for concrete/cement testing

Yes (on request)

Dimensions
(w x d x h)

480 x 900 x 2150 mm

Weight approx.

400 kg




Price/Info : Yudhistira, ST

Hp. 0811 188 6845; 0818 0816 0634(WA)

Email : naysite2@gmail.com
